20 watt Commercial LED Downlight Retrofit; 6 inch; 3000K; 120-277 volt (S9794)
$119.48
Call For Price
Enlarge Image
Add to Cart
Description:
20 watt Commercial LED Downlight Retrofit; 6 inch; 3000K; 120-277 volt
Availability:
  • Manufacturer has 106 items available.
  • This Item has been Discontinued. Please verify product pricing and availability with vendor prior to submitting any orders.
Required Components:

Optional Accessory:

Dimensions:
right arrow Height: 8.28"
right arrow Width: 7.56"
Additional Details:
right arrow Finish: Silver / White
right arrow Category: Recessed
right arrow Sub Category: Commercial
right arrow Style: Utility
right arrow Bulb Hours: 50000
right arrow Bulb Kelvin: Warm White
right arrow Bulb Shape: Integrated LED
right arrow Bulb Type: LED
right arrow Diameter: 7.56
right arrow Dimmable: Yes-Dimmable
right arrow Harmonized Codes: 8539.50.0091
right arrow Lumens: 1500L
right arrow Ship Carton Height: 9.06
right arrow Ship Carton Length: 10.63
right arrow Ship Carton Width: 9.25
right arrow Warranty: 5 Year Limited - Fixtures
right arrow Amps: 0.167-0.072A
right arrow ANSI Base: Integrated
right arrow BAA Compliant: No
right arrow Beam Spread: 40
right arrow CA Prop-65: Lead
right arrow Carton Cubic Feet: 0.5155
right arrow Cartons Per Unit: 1
right arrow CCT Selectable: No
right arrow CEC: T20 Exempt - Fixtures Not Regulated
right arrow CEC Terse: Lawful for sale in California
right arrow CEC Web Text: Lawful for sale
right arrow Connection: Direct Wired
right arrow Country Of Origin: China
right arrow CRI: 90+
right arrow Dimmable Down To: 100 to 20 percent
right arrow Dimmable Function: 0-10V Dimming Only
right arrow Efficacy: 75.00 LPW
right arrow FCC Compliant: Yes
right arrow Finish Family: Silver
right arrow Fixture shape: Round
right arrow Flr Equiv: 2 x 18W CFL
right arrow Incandescent Equivalent: 100W
right arrow Indoor Outdoor: Indoor
right arrow JA8 Compliant: No
right arrow Mounting Procedure: Ceiling
right arrow Operating Temprature: -20C (-4F) to +45C (+113F)
right arrow Order In Multiples Of: 1
right arrow Pack Type: Box
right arrow Power Factor: 0.99
right arrow Quantity In Pack: 1
right arrow Replaceable Light Source: No
right arrow RoHS Compliant: Yes
right arrow Safety Listing: cULus - Classified;cULus - Certified
right arrow SDS class: LED_Fixture
right arrow Short Description: 20WLED/CDL/6/30K/120-277
right arrow Temperature (CCT): 3000K
right arrow Title 20 Compliant: Exempt
right arrow Title 24 Compliant: No
right arrow Trim Color: Silver
right arrow Wattage Selectable: No
right arrow Standard Category: Recessed Ltg.
right arrow Standard Subcategory: Other Recessed Ltg.
right arrow Standard Finish: White , Silver
right arrow Standard Option: LED , Prop 65 prop65.png
Internal #:
X3N0C
